Catalog #
STAR-440W-M60H-M10
Mfr. Part #
STAR-440W-M60H-M10
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:

Technical Specifications

Watts STC
440 W
Cells
120
Technology
Monocrystalline
Open Circuit Voltage (Voc)
41.2
Short Circuit Current (Isc)
13.54
Max Power Voltage (Vmpp)
34.5
Max Power Current (Impp)
12.74
Max Current
20 A
Efficiency
20.31
Max System Voltage
1500 V
Frame Material
Aluminum
Frame Thickness (mm)
35
Frame Color
Black
Connector
MC4
Output Cables
1200mm
Series Fuse Rating (Amps)
20
Temp Coefficient (Pmpp)
-0.37
Temp Coefficient (Voc)
-0.29
Fire Classification (Type)
Type 1

General Information

Dimensions
1910 L x 1134 W x 35 H mm
Weight
24 Kg.
Approvals
UL61730-1/-2
UL61215-1/-2
CSA C22.2#61730-1/-2

Datasheets
