Catalog #
SIL 410 HC+
Mfr. Part #
SIL 410 HC+
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
Technical Specifications
Watts PTC
306
Watts STC
410 W
Cells
132
Technology
PERC
Open Circuit Voltage (Voc)
45.59
Short Circuit Current (Isc)
11.15
Max Power Voltage (Vmpp)
38.99
Max Power Current (Impp)
10.52
Max Current
20 A
Efficiency
20.7
Frame Material
Anodized Aluminum
Frame Thickness (mm)
35
Frame Color
Black
Backsheet Material
High durability, superior hydrolysis and UV resistance, multi-layer dielectric film, fluorine-free PV backsheet
Connector
Staubli MC4
Output Cables
1350 mm, φ 5.7 mm
Temp Coefficient (Pmpp)
-0.36
Temp Coefficient (Voc)
-0.28
Fire Classification (Type)
Type 2
General Information
Dimensions
1914 L x 1036 W x 35 H mm
Weight
47 Lbs.
Series
Silfab Prime
Approvals
UL 61215-1:2017 Ed.1
UL 61215-2:2017 Ed.1
UL 61730-1:2017 Ed.1
UL 61730- 2:2017 Ed.1
CSA C22.2#61730-1:2019 Ed.2
CSA C22.2#61730-2:2019 Ed.2
IEC 61215-1:2016 Ed.1
IEC 61215-2:2016 Ed.1
IEC 61730-1:2016 Ed.2
IEC 61730-2:2016 Ed.2
IEC 61701:2020
IEC 62716:2013
UL Fire Rating: Type 2
CEC Listed.
