Catalog #
REC410AA PURE
Mfr. Part #
REC410AA PURE
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
Technical Specifications
Watts PTC
312
Watts STC
410 W
Cells
132
Technology
HJT
Open Circuit Voltage (Voc)
49.4
Short Circuit Current (Isc)
10.42
Max Power Voltage (Vmpp)
42.2
Max Power Current (Impp)
9.72
Max Current
25 A
Efficiency
22.2
Frame Material
Anodized Aluminum
Frame Thickness (mm)
30
Frame Color
Black
Backsheet Material
Highly resistant polymer
Connector
Staubli MC4 PV-KBT4/KST4, 12 AWG (4 mm²)
Output Cables
12 AWG (4 mm²) PV wire, 43+ 47 in (1.1 + 1.2 m)
Temp Coefficient (Pmpp)
-0.26
Temp Coefficient (Voc)
-0.24
Fire Classification (Type)
Type 2
General Information
Dimensions
1821 L x 1016 W x 30 H mm
Weight
45 Lbs.
Series
Alpha Pure
Approvals
IEC 61215:2016
IEC 61730:2016
UL 61730
IEC 62804
IEC 61701
IEC 62716
UL 61730
IEC 62782
IEC 61215-2:2016
IEC 62321
ISO 14001
ISO 9001
IEC 45001
IEC 62941
