Catalog #
Q.PEAK DUO BLK-G10+ 365
Mfr. Part #
Q.PEAK DUO BLK-G10+ 365
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
Technical Specifications
Watts PTC
273.8
Watts STC
365 W
Cells
120
Technology
Q.ANTUM DUO Z
Open Circuit Voltage (Voc)
41.21
Short Circuit Current (Isc)
11.07
Max Power Voltage (Vmpp)
34.58
Max Power Current (Impp)
10.56
Max Current
20 A
Efficiency
20.3
Frame Material
Anodized Aluminum
Frame Thickness (mm)
32
Frame Color
Black
Backsheet Material
Composite Film
Connector
Staubli MC4; IP68
Output Cables
4 mm2 Solar cable; (+) ≥1150mm, (-) ≥1150mm
Temp Coefficient (Pmpp)
-0.34
Temp Coefficient (Voc)
-0.27
Fire Classification (Type)
Type 2
General Information
Dimensions
1717 L x 1045 W x 32 H mm
Weight
43.9 Lbs.
Series
Q.Peak Duo BLK G10+
Approvals
Quality Controlled PV - TUV Rheinland; IEC 61215:2016; IEC 61730:2016
