Catalog #
JKM580N-72HL4-BDV.35MC
Mfr. Part #
JKM580N-72HL4-BDV.35MC
Manufacturer
Category
Unit Price
For wholesale pricing and availability contact your local Greentech Renewables or:
Technical Specifications
Watts PTC
437
Watts STC
580 W
Cells
144
Technology
N-Type TOPCon
Open Circuit Voltage (Voc)
52.5
Short Circuit Current (Isc)
13.95
Max Power Voltage (Vmpp)
43.88
Max Power Current (Impp)
13.22
Max Current
30 A
Efficiency
22.45
Frame Material
Anodized Aluminum Alloy
Frame Thickness (mm)
35
Frame Color
Silver
Backsheet Material
2.0mm, Heat Strengthened Glass
Connector
MC4
Output Cables
12 AWG, 1400mm (55.12in)
Temp Coefficient (Pmpp)
-0.29
Temp Coefficient (Voc)
-0.25
Fire Classification (Type)
Type 29
General Information
Dimensions
2278 L x 1134 W x 35 H mm
Weight
70.55 Lbs.
Series
Eagle 72 G6B
Approvals
ISO9001:2015 Quality Standards
ISO14001:2015 Environmental Standards
IEC61215
IEC61730 certified products
ISO45001: 2018 Occupational Health & Safety Standards
UL61730 certified products
